ASTM A53 GR.B ERW Pipe

ASTM A53 Grade B ERW Pipe is a carbon steel pipe that comes under the ASTM A53 specification. The pipes range in dimensions according to the ASTM, ASME and API standards.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

introduction

With an annual output of 1 million tons, GNEE is the largest ERW pipe manufacturer and service provider in China. The ASTM A53 Grade B ERW pipe produced is a carbon steel pipe that meets the ASTM A53 specification. Pipe size ranges comply with ASTM, ASME and API standards.
ASTM A53 GR.B steel pipes are produced using a resistance welding process that uses resistance heat to weld steel plates together to form the pipe body. This kind of steel pipe has good strength and structural stability and can meet the high requirements for sealing and reliability of fluid delivery systems.
ASTM A53 B pipe has nominal bore sizes ranging from ½ inch to 36 inches.
If you need it for your project, please contact us in time!

ASTM A53 Grade B Carbon Steel Pipe Application
1. Architecture: maximum pipeline under more groundwater extraction when towers, boilers, hot water conveyance and so on.
2. Machining, bearing sets, processing machinery and other accessories.
3. Electrical class: gas distribution, water power fluid conduit.
4. Anti-static tubes wind power plants.

Data table

Grade and Chemical Composition (%) Of ASTM A53 Grade B ERW Black Pipe

Type

Grade

C≤

M≤

P≤

S≤

Cu≥

Ni≤

Mo≤

Type E

(electric-resistance welded)

0.25

0.95

0.05

0.045

0.4

0.08

0.3

1.2

0.05

0.045

0.4

0.08

Mechanical Properties Of ASTM A53 Grade B ERW round tube

Grade

Rm Mpa Tensile Strength

Mpa Yield Point

Elongation

Delivery Condition

≥330

≥205

Annealed

≥415

≥240

Annealed

Specifications: ASTM A53, ASME SA53 a53 erw pipe
Dimensions: ASTM, ASME and API
Type: Seamless / ERW / Welded / Fabricated
Size：Out Diameter:1/2"-24"
Wall Thickness: 1.65-20mm
Thickness: 3-12mm
Schedules: SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Length : 3-12m, or according to customer's requirement
End : Plain End, Beveled End, Treaded

company advantage

Why Choose GNEE

GNEE has 14 steel production lines, 10 processing equipment for processing, bending, painting, heat treatment, cutting, drilling, beveling, tempering, surface treatment, etc. It has complete testing equipment and strong technical force. The annual production capacity is more than 60,000 tons. And exported 10,000 tons of A214 carbon steel pipes.

FAQ
Q.Why choose Gnee?
A.With us, you will get the most competitive price, guaranteed quality, guaranteed delivery and after-sales service.
Q. Do you have a quality control system?
A.Yes, we have our own quality control laboratory.
Q.What is your lead time?
A.Generally, our delivery time is within 7-45 days.
