ASTM A671 Carbon Steel EFW Pipe
ASTM A671 Carbon Steel EFW Pipe
ASTM A671 EFW Pipe
ASTM A671 Carbon Steel Pipe
ASTM A671 Carbon Steel EFW Pipe
ASTM A671 Carbon Steel EFW Pipe
ASTM A671 EFW Pipe
ASTM A671 Carbon Steel Pipe

ASTM A671 Carbon Steel EFW Pipe

ASTM A671 specification nominally covers pipe 16 in. (405 mm) in outside diameter or larger and of 1/4 in. (6.4 mm) wall thickness or greater.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Technical Data
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A671 Carbon Steel EFW Pipe is a carbon-based stainless steel alloy containing elements such as carbon, silicon, and manganese, as well as trace amounts of phosphorus and sulfur.
Its mechanical properties are improved by alloying elements, with a yield strength of approximately 240 MPa and a tensile strength ranging from 450 MPa to 585 MPa. Pipe ends are available in a variety of styles, including beveled, flat, grooved, square cut, etc. with plastic protective caps. Threaded ends and splice ends are also available.
Surface treatment includes coatings such as EP, PE PP, FBE, anti-corrosion oil and black paint, or painting or galvanizing to improve corrosion resistance. ASTM A671 EFW Pipes are used in a wide range of applications including shipbuilding, oil and gas, fertilizers, manufacturing and other industries to transport fluids and gases from the site to the factory. Pipes undergo several tests such as hydrostatic testing or ultrasonic testing, eddy current testing and non-destructive testing, and their physical and chemical properties are checked.
Technical Data

Mechanical Properties Of A671 Pipes

Products Steel Grade BASE METAL MECHANICAL COMPOSITION Welding point tensile strength (N/mm2) Remarks
Yield point (N/mm2) Tensile Stregth (N/mm2) Test Pieces Elongation (%)
Pipes for pressure service ASTM A671, A672 -/A45 -/165 -/310~450 - -/30 -/310~450 A671/ A672
-/A50 -/185 -/345~485 -/28 -/345~485
CA55/A55 205 380~515 27 380~515
-/B55 -/205 -/380~515 -/27 -/380~515
CB60/B60 220 415~550 25 415~550
CB65/B65 240 450~585 23 450~585
CB70/B70 260 485~620 21 485~620
-/C55 -/205 -/380~515 -/27 -/380~515
CC60/C60 220 415~550 25 415~550
CC65/C65 240 450~585 23 450~585
CC70/C70 260 485~620 21 485~620
company advantage
gnee has 2.6 million tons of seamless steel pipes, carbon steel pipes, alloy steel pipes, stainless steel pipes and other metal materials, and 1.95 million tons of inventory. It has a first-class marketing service system, strong storage and transportation capabilities and complete processing and distribution capabilities. Our products have been exported to Europe, America, the Middle East, Southeast Asia, Central Asia, Africa, Oceania and other parts of the world.

FAQ

Q:Are you a factory or trading company?
A:We are professional manufacturer for steel pipe, and our company also is a veryprofessional a trade company for steel products.we can also provide a wide range of steelproducts.
Q:How many specifications does the product have and does it supportcustomization?
A:Make most grades and specifications, meet your different requirements.Focus on OEMODM service and customized service, meet differentcustomers'needs.
Q:What do your factory do regarding quality control?
A: We have obtained ISO, CE and other certifications. From materials to products, we checkevery process to maintain good quality.
Q.What is ASTM A671 GR CC60 material?
A.ASTM A671 CC60 covers standard specifications for electric welded fusion steel pipes. The ASTM A671 Gr CC60 Class 22 is made of main constituents of carbon, silicon, phosphorous, and sulfur.

Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
Related Projects
