JIS G3473 carbon steel hydraulic cylinder tube is usually made of high-quality carbon steel, which has good mechanical properties and certain corrosion resistance, and can adapt to the high pressure and complex working environment in the hydraulic system.

standard:JIS

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

Data table

Related Products

Service

Related Projects

Inquiry

introduction

JIS G3473 Hydraulic Cylinder Pipe‌ is a carbon steel pipe specially designed for hydraulic cylinder applications, with standards and specifications designed to ensure the performance and safety of hydraulic systems. This pipe generally has high pressure bearing capacity and good corrosion resistance to meet the needs of hydraulic cylinders in various working environments.
GNEE also provides hydraulic cylinder pipes produced according to JIS G3473 standards that can be processed in various ways, such as cutting, welding, bending, etc. to meet specific installation and use requirements. In addition, these pipes can also be surface treated, such as galvanizing or coating, to improve corrosion resistance and aesthetics.

Data table

Chemical composition and Mechanical properties of JIS G3473:

Steel Grade	C max	Si max	Mn max	P max	S max
STC 370	0.25	0.35	0.3-0.90	0.04	0.04
STC 440	0.25	0.35	0.30-0.90	0.04	0.04
STC 510 A	0.25	0.35	0.30-0.90	0.04	0.04
STC 510 B	0.18	0.55	1.5	0.04	0.04
STC 540	0.25	0.55	1.6	0.04	0.04
STC 590 A	0.25	0.35	0.30-0.90	0.04	0.04
STC 590 B	0.25	0.35	1.5	0.04	0.04

MECHANICAL PROPERTIES min
Steel grade	Tensile strength Mpa	Yeild point or proof stress Mpa	Elongation %
Steel grade	Tensile strength Mpa	Yeild point or proof stress Mpa	Elongation %
STC 370	370	251	30
STC 440	440	305	10
STC 510 A	510	380	10
STC 510 B	510	380	15
STC 540	540	390	20
STC 590 A	590	490	10
STC 590 B	590	490	15

JIS G3473 Seamless Steel Tubes Sizes and tolerances
Specified outside diameter with tolerance: 4 (+/-0,08) to 300 (+/-0,35) mm
Specified inside diameter with tolerance: 2 (+/-0,15) to 100 (+/-0,35) mm
Lengths: standard length of 6 m ; exact length ; other length
Straightness: The deviation from straightness of any tube length L shall not exceed 0,0015 L. Deviations from straightness over any one metre length shall not exceed 3 mm.

company advantage

Why Choose GNEE

GNEE currently covers an area of 35,000 square meters, with a production area of 10,000 square meters. There are 200 employees, including 20 engineers and technicians. The company has seven management departments, including procurement, technology, quality inspection, sales, production, company office, and finance; as well as three production workshops, including pipeline system, membrane wall, collector box, module, and paint packaging. It has advanced automatic welding equipment and testing equipment such as submerged arc automatic welding of membrane modules and automatic welding of finned tubes.

FAQ

Q: Do you have quality control?
A: Yes, we have gained BV, SGS authentication.
Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.
