ASTM A252 Mechanical Structural Pipe

ASTM A252 pipe piles are typically used in construction projects involving deep foundations, such as bridge and building construction, marine structures, and retaining walls.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

ASTM A252 is a standard specification for seamless and welded carbon steel pipe piles developed by the American Society for Testing and Materials (ASTM).
The ASTM A252 standard covers different grades of mechanical structural pipes, including GR.1 and GR.2, which are commonly used in piling and civil engineering.
GNEE supplies ASTM A252 piling pipes in various specifications, including seamless steel pipes, ERW steel pipes, SSAW steel pipes, and LSAW steel pipes, with a variety of options for outer diameter and wall thickness to meet different engineering needs.
ASTM A252 seamless steel pipes have an outer diameter range of 21.3 mm to 1473 mm and a wall thickness range of 2 mm to 300 mm.
ASTM A252 ERW steel pipes have an outer diameter range from 33.4 mm to 609.6 mm and a wall thickness range of 2 mm to 30 mm.
The outer diameter of ASTM A252 SSAW steel pipes ranges from 219 mm to 3200 mm, and the wall thickness ranges from 5 mm to 30 mm.
The outer diameter of ASTM A252 LSAW steel pipes ranges from 457 mm to 1422 mm, and the wall thickness ranges from 8 mm to 50 mm.

Data table

ASTM A252 Steel Pipe Pile Chemical Composition:

Composition, %	C, max	Si, max	Mn, max	P, max	S, max
Grade 1	0.26	0.45	1.6	0.05	0.03
Grade 2	0.26	0.45	1.6	0.05	0.03
Grade 3	0.26	0.45	1.6	0.05	0.03

ASTM A252 Piling Pipe Mechanical properties:

Mechanical Property	Grade 1	Grade 2	Grade 3
Minimum Yield strength ReH MPa	205	240	310
Tensile strength Rm MPa	345	415	455
Minimum elongation A %	30	25	20

company advantage

GNEE company implements API SPEC 5CT, API SPEC5L, ASTMA53, CB/T9711.1, GB/T9711.2, GB/T13793, SY/T5768 and other international and domestic standards, which can meet the needs of customers with different standards.

GNEE Additional value-added services
UT(Ultrasonic examination)
AR(As Hot Rolled only)
TMCP (Thermal Mechanical Control Processing)
N(Normalized)

FAQ
1.Q.Why choose you?
A.Firstly quality, secondly price, we can give you both. Our service formula: good quality + good price + good service = customer's trust.
2. Q: What services do you provide?
A: Customized service for each customer, please feel free to contact us!
3.Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
