ASTM A423 Grade 1 Seamless Steel Tubes
ASTM A423 Grade 1 seamless steel pipe is a seamless steel pipe produced in accordance with ASTM A423 standards, and its quality grade is Grade 1.
Chemical composition % of 13CrMo4-5 (1.7335) steel pipe
| C | Si | Mn | P | S | Cr | Mo | N | Cu |
| 0.08 - 0.18 | max 0.35 | 0.4 - 1 | max 0.025 | max 0.01 | 0.7 - 1.15 | 0.4 - 0.6 | max 0.012 | max 0.3 |
Mechanical properties of steel 13CrMo4-5 (1.7335) Alloy Steel Seamless Pipes
| Nominal thickness (mm): | to 60 | 60 - 100 | 100 - 150 | 150 - 250 |
| Rm - Tensile strength (MPa) | 450-600 | 440-590 | 430-580 | 420-570 |
Specifications for 13CrMo4-5 alloy steel tube
| Nominal thickness (mm): | to 16 | 16 - 60 | 60 - 100 | 100 - 150 | 150 - 250 |
| ReH - Minimum yield strength (MPa) | 290-300 | 290 | 270 | 255 | 245 |
EN 10216-2 13CrMo4-5 Seamless Alloy Steel Tube/pipe
Standard: EN10216-2
Materials: 13CrMo4-5
Technical: Normalizing, Quenching and Tempering, Normalizing and Tempering.
Application: used in the power plant boiler tubes, etc
Size: Outside diameter 10.2-711 mm; Wall thickness 1.6-100mm; Length: 5.8m-12m or random
Payment Terms:T / T, LC
Delivery: 7-15 days after payment
Surface: Tubes will be varnished (Outside only) to prevent rust.
Marking: Standard + Steel Grade + Size + Heat No + Lot No
Package: Bundles (hexagonal),Wooden Boxes,Crates (steel/wooden) or as required
Why choose GNEE 13crmo4-5 alloy tube
GNEE is a supplier and exporter of high quality EN 10216-2 alloy steel seamless pipes.
GNEE offers seamless pipes in different sizes, grades, thicknesses and specifications required by its customers. We also provide customers with market competitive prices.
If you are looking for 13crmo4-5 seamless pipe, please contact us in time to get a quote!
FAQ
Q.Is hot rolled pipe seamless?
A.Hot-rolled pipes are pipe fittings produced through hot-rolling processes and are common mechanical structural parts.
Q.What services do you provide?
A.Customized service for each customer, please feel free to contact us!
Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
