EN 10305-1 C35E Honed Seamless Steel Pipe

EN 10305-1 C35E Honed Seamless Steel Pipe

EN 10305-1 C35E grade pipe is ductile and strong with long-term wear characteristics. These tubes are manufactured to EN specifications and are commercially known as carbon steel tubes.

standard:EN

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

GNEE specializes in the production of EN 10305-1 C35E honed seamless steel pipes. EN 10305-1 is a European standard on the technical delivery conditions of precision steel pipes, which details the technical requirements for seamless cold-drawn steel pipes.
C35E is a material designation for special steel with good forgeability, strength, toughness and wear resistance, and is suitable for applications in forging or normalizing conditions.
Honing is a finishing method used to improve the internal surface finish and accuracy of steel pipes.
C35E cold drawn steel pipe has high precision, high smoothness and excellent mechanical properties, and is suitable for applications that require high inner surface quality and mechanical properties of steel pipes.

Data table

Chemical composition % of c35e seamless corten steel tube pipe

C	Si	Mn	Ni	P	S	Cr	Mo
0.32 - 0.39	max 0.4	0.5 - 0.8	max 0.4	max 0.045	max 0.045	max 0.4	max 0.1

Mechanical properties of C35E 1.1181 Mechanical Seamless Carbon pipe

Nominal thickness (mm):	to 16	16 - 100	100 - 250	250 - 500	500 - 1000
Rm - Tensile strength (MPa) (+N)	550	520	500	480	470

company advantage

Our advantage

GNEE's EN10297 C35E seamless pipe manufacturing process begins with extruded hollow pipe or solid bar stock, drilled to our exacting specifications. The material is then reduced in size multiple times through various cold working techniques until it reaches the specific dimensions, tolerances and temper required by the customer. After each cold working cycle, the tubes are cut, cleaned and heat treated to prepare them for the next cold working step.
GNEE can implement GB, ASTM, JIS, DIN and other standards. If you are looking for C35E pipe, please contact us in time to get a quote!

FAQ
Q.What is cold drawn seamless pipe?
A.The cold drawing process improves the physical properties of the material and provides tighter tolerances compared to hot-rolled products.
Q.What services do you provide?
A.Customized service for each customer, please feel free to contact us!
Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
