ASME SA-556M Grade C2 Seamless Pipe

ASME SA-556M Grade C2 seamless pipe is a high-temperature seamless steel pipe produced in accordance with the American Society of Mechanical Engineers (ASME) standard SA-556M.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

ASME SA-556M Grade C2 seamless pipe is a high-temperature seamless steel pipe produced in accordance with the American Society of Mechanical Engineers (ASME) standard SA-556M. Grade C2 indicates that the steel pipe is suitable for high-temperature service under moderate pressure.
ASME SA-556M C2 seamless cold drawn tubing is used in tubular feed water heaters to preheat water before it enters the boiler to produce steam. SA-556M C2 is pearlescent carbon steel used for tubular water heaters in the ASME SA-556m standard. It is divided into straight tubes and tubes that need to be bent into a "U" shape.
This specification is similar to ASTM A556/A556M and also covers seamless cold-drawn carbon steel tubing for use in tubular feedwater heaters, including bending into U-shaped tubing if specified.
SA-556M C2 pipe is widely used in petroleum, chemical, electric power, shipbuilding and other industrial fields, especially in equipment and systems that need to withstand high temperatures and high pressures.

Technical Data

Technical standard requirements

Chemical composition of SA-556M Grade C2 steel tubes

Grade	C	Si	Mn	P	S
SA-556M C2	≤0.30	≥0.10	0.29-1.06	≤0.035	≤0.035

Mechanical properties of SA-556M Grade C2 steel tubes

Mechanical properties	Grade C2
Tensile strength, min, ksi [MPa]	70 [480]
Yield strength, min, ksi [MPa]	40 [280]
Elongation in 2 in. or 50 mm, min, % (longitudinal)	30
Hardness	HR B 89
