EN 10216-2 16Mo3 Alloy Steel Pipe

EN 10216-2 16Mo3 alloy steel pipe‌ is an important industrial material, widely used in various high temperature and high pressure industrial environments.

standard:EN

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

EN 10216-2 16Mo3 seamless pipe is a chromium-molybdenum (Cr-Mo) alloy steel, 16Mo3 steel number is 1.5415, it is a European (DIN EN) alloy steel grade. It is mainly used for high temperature refinery pipelines, steam pipelines and power plant projects.
GNEE's 16Mo3 steel pipes need to go through hot rolling, heat treatment and inspection process steps. Hot rolling can refine the grain of steel and improve its mechanical properties; heat treatment controls parameters such as heating temperature, holding time and cooling rate. 16Mo3 seamless alloy pipes can be provided in different product forms according to relevant EN standards.

Data table

chemical composition of EN 10216-2 16Mo3 seamless alloy pipe

Element	Content by Mass, %
Carbon (C)	0.12~0.20
Silicon (Si)	≤0.35
Manganese (Mn)	0.40~0.90
Phosphorus (P)	≤0.025
Sulfur (S)	≤0.020
Chromium (Cr)	≤0.30
Molybdenum (Mo)	0.25~0.35
Nickel (Ni)	≤0.30
Aluminium (Al)	≤0.040
Copper (Cu)	≤0.30

Mechanical properties of EN 10216-2 16Mo3(1.5415) seamless pipes

Yield Strength for Wall Thickness T, Min. MPa			Tensile Strength MPa
T ≤ 16	16 < T ≤ 40	40 < T ≤ 60	-
280	270	260	450~600

company advantage

Why choose GNEE EN 10216-2 pipe

GNEE has 12 production lines with an annual output of 50,000 tons and has obtained the ISO9001 international quality management system certificate.
We also have 10 processing equipments including processing, bending, painting, heat treatment, cutting, drilling, beveling, tempering, surface treatment, etc., complete testing equipments and strong technical force. Annual production capacity is more than 200,000 tons.
If you are looking for this kind of steel pipe, please contact us for a quote!

FAQ

Q.Why choose Gnee?
A.With us, you will get the most competitive price, guaranteed quality, guaranteed delivery and after-sales service.

Q.Do you have a quality control system?
A.Yes, we have our own quality control laboratory. Third party testing service is also available.

Q: Can we visit your factory?
A: Sure, we welcome you to visit our factory, check our production lines andknow more about our strength and quality.
