JIS G4105 SCM440 Alloy Steel Tubing

JIS G4105 SCM440 alloy structural pipe is a high strength, high hardness alloy structural steel with good ductility and toughness.

standard:JIS

Surface :1. Galvanized 2. Black and Color Painting

introduction

JIS G4105 SCM440 seamless pipe is a chromium alloy structural steel containing 0.9-1.2% Cr, and is commonly used to manufacture gears, pump shafts and tool holders. This steel has high strength and good comprehensive mechanical properties, and is suitable for high temperature working environments. The maximum operating temperature can reach 427℃. Its heat treatment specifications are 880℃ oil quenching, 650～680℃ tempering, air cooling, and the metallographic structure is tempered martensite. The advantages of JIS G4105 SCM440 seamless alloy steel pipe include good processability, impact absorption performance, and easy welding. This steel is widely used in the production of high-strength fasteners, such as engines and molds.

Data table

Standards: JIS G4051
Size: 26.9-610mm*2.3-45mm*5.8-12m
Forms: Steel round tubing
Delivery condition: Cold drawing, hot rolling, forging

Chemical composition of JIS G4105 SCM440 Alloy Steel Tubing

C	Si	Mn	Cr	Mo	Ni	P	S
0.38-0.43	0.15-0.35	0.6-0.85	0.9-1.2	0.15-0.3	≦0.25	≦0.03	≦0.03

Mechanical Properties of JIS G4105 SCM440 Steel Tubing

Tensile Strength (kgf/mm²)	Yield Strength 0.2% (MPa)	Elongation -% in 50 mm (min.)	Hardness, HB
≥1080(110)	≥930(95)	17	285~352

company advantage

Why Choose GNEE

GNEE has established ISO9001:2008 quality management system and implemented comprehensive quality management. It currently sells 200,000 tons of steel pipes each year, and its products cover high, medium and low pressure boilers, ships, liquid transportation pipes, etc. It is exported to more than 60 countries and regions including Russia, Canada, India, Brazil, Southeast Asia, etc.
If any question,please contact with us freely by E-mail or Telephone.

FAQ

Q: Can provide OEM/ODM service?
A: Yes. Please feel free to contact us for more details discuss.
Q: How is your Payment Term?
A:One is 30% deposit by TT before production and 70% balance against copy of B/L.
Q: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
