ASME SA335 P9 Alloy Steel Seamless Pipes

ASME SA335 P9 Alloy Steel Seamless Pipes

A335 P9 seamless pipe is a high performance alloy steel pipe, mainly used in high temperature and high pressure environment.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

ASME SA335 P9 seamless pipe is mainly composed of elements such as chromium and molybdenum. It is a low-alloy high-strength steel pipe. It is widely used in high-temperature, high-pressure, flammable and explosive pipelines in petroleum refining plants, especially direct heating pipes in heating furnaces, and the medium temperature can reach 550~600℃.
The production process of SA335 P9 alloy steel seamless pipe provided by GNEE strictly follows the ASTM A335/A335M standard and adopts advanced seamless ferrite alloy steel production technology.
The production methods include hot rolling, cold drawing and hot expansion, and the delivery state is heat treatment.

Data table

ASTM A335 Grade P9 Alloy Steel Pipe Composition

C, %	Mn, %	P, %	S, %	Si, %	Cr, %	Mo, %
0.015 max	0.30-0.60	0.025 max	0.025 max	0.50 max	4.00-6.00	0.45-0.65

ASTM A335 Grade P9 Seamless Pipe Properties

Tensile Strength, MPa	Yield Strength, MPa	Elongation, %
415 min	205 min	30 min

Specifications
Standards : ASTM A 335, ASME SA 335
Type : Seamless
Specialized in : Large Diameter Size
Outer Dimensions : 19.05mm – 114.3mm
Wall Thickness : 2.0mm – 14 mm
Length : max 16000mm

company advantage

Why Choose GNEE

GNEE exports A335 steel pipes to 65 countries and regions around the world every year. The price is 5% lower than other suppliers, the production quality is strictly guaranteed, and there is a professional after-sales service team of 20 people. We will solve any doubts for you and provide project solutions! If you are looking for A335 p9 boiler tubes, please contact us in time to get a quote!

FAQ

Q: How about the samples? Is it free or extra fees?
A: Usually, we would like to supply the samples before order. If the samples are in stock, it will be free. If the samples need to be produced, we will charge some reasonable cost. But this amount will be deducted from your first order invoice.
Q: How long is your delivery time?
A: Our daily inventory is more than 8000 tons, so common products size orders just need 7 days from stocks. If there are special size orders, it will cost 7-15 days.
