ASTM A423 Grade 1 Corten Steel Pipe

Weather-resistant ASTM A423 Grade 1 steel pipe, suitable for pressure-containing components such as economizers or other applications requiring corrosion resistance.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

introduction

ASTM A423 A Grade 1 Steel Pipe is a corrosion resistant alloy steel pipe, which indicates the application in corrosion resistant and high temperature environment. It does not allow various corrosion resistance requirements must be within the range.
The chemical composition of ASTM A423 Grade 1 Seamless Steel Pipe includes elements such as carbon, manganese, sulfur, phosphorus, silicon, copper and nickel, which can resist the attack of corrosive media such as acid, brine, ammonia, and has the ability to resist stress corrosion cracking.

Data table

Chemical Composition Of ASTM A423 Gr.1 Alloy Steel Round Pipe

	C, %	Mn, %	P, %	S, %	Si, %	Cu, %	Cr, %	Ni, %	Mo, %	Sb, %
ASTM A423 Gr.1	0.15 max	0.55 max	0.06-0.16	0.060 max	0.10 min	0.20-0.60	0.24-1.31	0.20-0.70	-	-

Mechanical Properties Of Corten Steel Astm A423 Gr.1 Seamless Pipes

Tensile Strength, Mpa	Yield Strength, Mpa	Elongation, %
ASTM A423 Gr.1	415 min	255 min	25 min

Corten Steel ASTM A423 Pipe Specification

Corten Steel Tube Standards	ASTM A 423 GR. 1,ASME SA 423, ASTM A 847, ASTM 588, ASTM 606
Corten Steel Pipe Shape	Round, Square, Rectangle, Hydraulic, Honed Tubes
ASTM A423 Grade 3 Tube Length	Single Random, Double Random & Cut Length
Corten Steel Grade B Tube End	Plain End, Beveled End
Tubo ASTM A423 type	Weathering steel / corten steel

company advantage

Why Choose GNEE

The ASTM A423 Grade 1 Weathering Steel Pipe supplied by GNEE has various stock forms such as seamless, welded, prefabricated, electric resistance welded, round, square, rectangular, hydraulic, polished, threaded end, plain end, etc. All these weathering steel pipes are packed with environmentally friendly packaging materials and delivered to customers in a timely and damage-free manner.
If you would like to know more about our company or our products, please feel free to contact us.

FAQ
Q: Do you have quality control system?
A: Yes, we have our own quality control laboratory.Third party testing servicesare also available.
Q: What services do you provide?
A: Customized service for each customer, please feel free to contact us!
Q.What is your lead time?
A. Regular stock is usually 10 days. Depends on the products.
