AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe
AISI 1018 Seamless Steel Pipe

AISI 1018 Seamless Steel Pipe

ASTM A519 1018 seamless steel pipe is a seamless steel pipe made of carbon structural steel.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A519 Grade 1018 Carbon Steel Seamless Tubings are Low Carbon Steel Tubings with 0.15-0.20 % carbon content with combination of 0.60-0.90 % manganese.
In terms of physical properties, AISI 1018 seamless steel tubes have a relatively low density of about 7.87 g/cm3, a hardness usually between HB130 and HB210, and moderate strength. In addition, its thermal expansion coefficient is small, making the steel tube less likely to change shape when the temperature changes.
Heat treatment
The heat treatment for AISI 1018 low carbon steel tube consists of the following processes:
Normalizing
AISI 1018 Carbon Steel Seamless Pipe should be heated at 890℃-940℃ and then cooled in still air.
Forging
This process requires heating between 1150℃-1280℃ and it is held until the temperature becomes constant.
900℃ is the minimum temperature required for the forging process.
The steel is then cooled in air after this process.
Tempering
AISI 1018 round carbon steel tubing  is tempered at between 150℃-200℃ for improvement of case toughness. This process has little or no effect on hardness.
Data table

Chemical composition of Carbon Steel AISI 1018 pipe

Element

Content

Carbon, C

0.14-0.20%

Manganese, Mn

0.60-0.90%

Phosphorous, P

≤0.040%

Sulfur, S

≤0.050%

Mechanical properties of 1018 Cold Drawn Seamless Round Steel Tubing

Mechanical Properties

Metric

Hardness, Brinell

126

Hardness, Knoop (Converted from Brinell hardness)

145

Hardness, Rockwell B (Converted from Brinell hardness)

71

Hardness, Vickers (Converted from Brinell hardness)

131

Tensile strength, Ultimate

440 MPa

Tensile strength, Yield

370 MPa

Elongation at Break (In 50mm)

15.0%

Reduction of Area

40.0%

company advantage

Advantages of Choosing GNEE steel pipe

GNEE has an advanced inspection and testing center that can conduct various physical and chemical tests on steel pipes before they leave the factory. It has successively obtained ISO9001, ISO14001, ISO45001 system certification, special equipment manufacturing license, API 5L certificate and API 2B certificate, CE certificate, safety production standardization second-level enterprise and other standard quality system certifications.
If you are looking for seamless pipe, please send us an email in time!


FAQ
Q.Do you have quality control?
A.Yes, we have got BV.SGS certification.
Q.What is your lead time?
A.Generally, our delivery time is within 7-45 days.
Q.What is your after-sales service?
A.We provide after-sales service and 100% quality assurance for our products.
