Corten Steel S355JOWP Structural Steel Pipe

S355JOW belongs to the European standard weather-resistant steel pipe. Weather-resistant structural steel is atmospheric corrosion-resistant steel and is a low-alloy high-strength structural steel.

standard:EN

Surface :1. Galvanized 2. Black and Color Painting

introduction

The weather resistance of S355J0WP weather-resistant steel pipe is 2 to 8 times that of ordinary carbon steel, and the paintability is 1.5 to 10 times that of ordinary carbon steel. At the same time, S355J0WP structural steel pipes are rust-resistant, making components resistant to corrosion and extending life, thinning and reducing consumption, and saving labor and energy.
S355J0WP alloy steel pipe is mainly used for steel structures such as railways, vehicles, bridges, and towers that are exposed to the atmosphere for a long time. It is used to manufacture structural parts such as containers, railway vehicles, oil derricks, harbor buildings, oil production platforms and containers containing hydrogen sulfide corrosive media in chemical and petroleum equipment.

Data table

S355JOWP round pipe Standards :

Atmospheric Corrosion Resistant Steel	EN Standard	Material No.
Atmospheric Corrosion Resistant Steel	S355JOWP ( 10025-5)	1.8946

S355JOWP Atmospheric Corrosion Resistant Steel Chemical Requirements :

C	Si	Mn	P	S	Cr	Cu	Ni
≤ 12	≤ 0.75	≤ 1.00	0.06 – 0.15	≤ 0.035	0.30 – 1.25	0.25 – 0.55	≤ 0.65

S355J0WP mechanical properties:
Tensile strength (σb/MPa)
＞3-≤16mm(thickness) 470-630
＞16-≤40mm (thickness) 470-630
＞40-≤63mm (thickness) 470-630
＞63-≤80mm (thickness) 470-630
Yield strength (σs/MPa)
＞3-≤16mm(Thickness) ≧355
＞16-≤40mm(thickness)≧345
＞40-≤63mm(thickness)≧335
＞63-≤80mm(thickness)≧325
Impact power ≥27J
