ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube
ASTM A210 A1 Seamless Boiler Tube

ASTM A210 A1 Seamless Boiler Tube

ASTM A210 A1 seamless boiler tubes are mainly used to manufacture headers, main steam pipes, etc. for the heating surface of high-pressure boilers, and are power station boilers and superheaters.
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
introduction
Data table
Related Products
Service
Related Projects
Inquiry
introduction
ASTM A210 / A210M, ASME SA210 / SA210M Grade A-1 is the standard applicable to Seamless Medium-Carbon Steel Boiler and Superheater Tubes.
ASTM A210 Grade A1 Seamless Boiler and Superheater Tubes sizes and thicknesses usually furnished to this specification are 1/2 in. to 5 in. in outside diameter and 0.035 to in. 0.500 , inclusive, in minimum wall thickness.
ASTM A210 specifies seamless medium carbon steel tubing for boiler and superheater tubes, applicable to boiler tubes and boiler flue tubes, including minimum wall thickness safety side, top and support tubes, and superheater tubes. ASTM A210 can be divided into two grades, A1 and C. Grade A1 is the most commonly used grade.
Data table

ASTM A210 Gr. A1 steel pipe  Chemical Composition:

Grade

C(Max)

Mn

Si(Min)

P(Max)

S(Max)

A1

0.27

Max.0.93

0.10

0.035

0.035

ASTM A210 Gr. A1 seamless alloy pipe physical property:

Grade

Tensile Strength(Mpa)

Yield Strength(Mpa)

Elongation (%)

A1

≥ 415

≥ 255

≥ 30


ASTM A210 Grade A1 Superheater Tubes
Manufacture:Seamless process ,Hot-finished or Cold-finished
Wall thickness(WT): 0.9 mm--12.7 mm.
Outer diameter (OD): 12.7 mm--127 mm
Length: 6M or specified length as required.
Ends: Plain End, Beveled End, Treaded
company advantage
Gnee is committed to the R&D, manufacturing and service of various types of special seamless steel pipes. With its excellent products, high-quality services and reasonable prices, Gnee is widely exported to more than 60 countries and regions in Europe, the United States, the Middle East, Southeast Asia, and Africa.

FAQ

1.Q.How do we trust your company?
A. We specialist in steel business for many years, authenticated by SGS,welcome to visit our factory.

2. Q: Can I get samples before order ?
A: Yes, of course. Usually our samples are free. we can produce by your samples ortechnical drawings.

3.Q.What is the composition of SA 210 GR C material?
A.SA 210 Grade C Boiler Pipes are composed of carbon, manganese, phosphorus, sulfur, & silicon.
