Corten Steel ASTM A242 Pipes

ASTM A242 is a specification for high strength low alloy structural steel pipes used in construction & other applications.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

ASTM A242 pipe is an alloy steel pipe manufactured according to American Society for Testing and Materials (ASTM) standards. These pipes are used in construction applications that require high strength, corrosion resistance, and heat resistance.
ASTM A242 alloy steel pipe is an alloy steel made from iron, carbon and other elements such as molybdenum, manganese, chromium, nickel, copper and vanadium. Typically, these pipes have a carbon content of 0.25% to 0.50%, with the remainder being alloy material.
ASTM A242 weathering steel pipe is a chromium-molybdenum alloy pipe with excellent weldability, formability, toughness and atmospheric corrosion resistance. Pipes have good wear resistance when surfaces such as valves, pumps and other components wear away.

Technical Data

Specifications For Corten Steel ASTM A242 Pipes & Tubes

Standards	ASTM A 242 / ASME SA 242
Grade	ASTM A 423 GR.1 , asme SA A423 , astm a 847, astm 606
Shape	Round, Square, Rectangle, Hydraulic, Honed Tubes
Length	Single Random, Double Random & Cut Length
End	Plain End, Beveled End
type	Weathering steel / corten steel

ASTM A242 Corten Steel ASTM A242 Seamless Pipes Chemical Requirements :

Grade	C	Mn	P	S	Cu
ASTM A242	0.15 max	1.00 max	0.15 max	0.05 max	0.20 min

CORTEN A242 Weathering Steel Tube Mechanical Properties :

Grade	Yield Strength Min Mpa	Tensile Strength Min Mpa	Elongation % (min)
ASTM A242	480	345	16
