ASME SA213 T92 Alloy Steel Seamless Tube

Description

We are one of the leading Manufacturers, Supplier and Exporters of high quality ASTM A213 T92 Alloy Steel Seamless Tube. we manufacture these using optimum quality material as per their specified details. These ASME SA213 T92 Alloy Steel Tubes are widely used in various application industry such as Oil & Gas, Power, Fertilizers, Heat-Exchangers, Paper & Pulp, pharmaceuticals, Chemicals, Water Treatment, Dairy etc. We offer these ASMT A213 / ASME SA213 T92 Alloy Steel SMLS Tube at competitive prices in the market.

SA213 T92 Boiler Tube Specification

Size (Seamless)	:	6.35mm o.d to 101.60mm o.d
Standards	:	ASTM A213, ASME SA213
Equivalent Standards	:	EN 10216-2, ASTM A213, GOST 550-75
Material	:	T92, K92460
Equivalent Material	:	P92
Type	:	Seamless
Specialized in	:	Large Diameter Size
Outer Dimensions	:	6-2500mm; WT:1-200mm
Wall Thickness	:	Schedule 3mm to 15mm.
Length	:	max 1~12m
Schedule	:	STD, SCH40, SCH80
Form	:	Round, Square, Rectangular, Hydraulic Etc.
Length	:	Single Random, Double Random & Cut Length.
Tubing End	:	Plain End, Beveled End, Treaded.

Technical data

Chemical Compositions of ASTM A213 / ASME SA213 T92 Alloy Steel SMLS Tubes

C, %

Mn, %

P, %

S, %

Si, %

Cr, %

Mo, %

V, %

N, %

Ni, %

Al, %

Nb, %

W, %

B, %

0.07-0.13

0.3-0.6

0.02 max

0.01 max

0.5 max

8.5-9.5

0.3-0.6

0.15-0.25

0.03-0.07

0.4 max

0.04 max

0.04-0.09

1.5-2.0

0.001-0.006

Mechanical Properties of ASTM A213 / ASME SA213 T92 Alloy Steel Seamless Tubes

Tensile Strength , MPa	Yield Strength, MPa	Elongation, %	Hardness, HB
585 min	415 min	20 min	250 max

Gr T92 Tubing Wall thickness & Tolerance

Hot rolled	Outside Diameter, mm	Tolerance, mm
	OD≤101.6	+0.4/-0.8
	101.6＜OD≤190.5	+0.4/-1.2
	190.5＜OD≤228.6	+0.4/-1.6
Cold Drawn	Outside Diameter, mm	Tolerance, mm
	OD＜25.4	±0.10
	25.4≤OD≤38.1	±0.15
	38.1＜OD＜50.8	±0.20
	50.8≤OD＜63.5	±0.25
	63.5≤OD＜76.2	±0.30
	76.2≤OD≤101.6	±0.38
	101.6＜OD≤190.5	+0.38/-0.64
	190.5＜OD≤228.6	+0.38/-1.14

ASTM A213 T92 Wall thickness & Tolerance

Hot rolled	Outside Diameter, mm	Tolerance, %
	OD≤101.6, WT≤2.4	+40/-0
	OD≤101.6, 2.4＜WT≤3.8	+35/-0
	OD≤101.6, 3.8＜WT≤4.6	+33/-0
	OD≤101.6, WT>4.6	+28/-0
	OD>101.6, 2.4＜WT≤3.8	+35/-0
	OD>101.6, 3.8＜WT≤4.6	+33/-0
	OD>101.6, WT>4.6	+28/-0
Cold Drawn	Outside Diameter, mm	Tolerance, %
	OD≤38.1	+20/-0
	OD>38.1	+22/-0
