API 5L X52 PSL2 Seamless Steel Pipe

API 5L X52 PSL2 seamless steel pipe is widely used in oil, natural gas and other fluid transportation fields.

standard:ASTM

Surface :1. Galvanized 2. Black and Color Painting

Quote Now

Send E-mail

introduction

API 5L X52 PSL2 Grade Carbon Steel Seamless Pipe is used in the oil and gas industry to transport oil, gas and water. API 5L X52 PSL2 Grade Pipe is available in both seamless and welded types, commercially known as API 5L Line Pipe.
API 5L X52 PSL2 Pipe has a high yield strength of 52,000 psi and is suitable for high pressure applications. It has equivalent ASTM specification A53 Grade B and EN10208 L360MB or GB/T9711 L360 and ISO3183 L360 as grades.

Data table

Chemical Composition Of API 5L X52 PSL2 Pipes With T ≤ 0.984"

Steel Grade	Mass fraction, % based on heat and product analyses									Carbon Equiv a
	C	Si	Mn	P	S	V	Nb	Ti	Other	CE IIW	CE Pcm
	max b	max	max b	max	max	max	max	max	Other	max	max
Seamless and Welded Pipe
X52N	0.24	0.45	1.4	0.025	0.015	0.1	0.05	0.04	d,e,l	0.43	0.25
X52Q	0.18	0.45	1.5	0.025	0.015	0.05	0.05	0.04	e,l	0.43	0.25

Mechanical Properties Tensile And Yield Of API 5L X52 PSL2 Pipe

Pipe Grade	Tensile Properties – Pipe Body of SMLS and Welded Pipes PSL 2						Seam of Welded Pipe
	Yield Strength a		Tensile Strength a		Ratio a,c	Elongation	Tensile Strength d
	Rt0,5 PSI Min		Rm PSI Min		R10,5IRm	(in 2in)	Rm (psi)
						Af %
	Minimum	Maximum	Minimum	Maximum	Maximum	Minimum	Minimum
X52N,X52Q,X52M	52,200	76,900	66,700	110,200	0.93	f	66,700

company advantage

Why Choose GNEE

GNEE has 12 production lines with an annual output of 50,000 tons. It has obtained the ISO9001 international quality management system certificate. The current warehouse inventory is more than 1,500 tons and more than 800 specifications. It is committed to strict quality control and thoughtful customer service.
Please feel free to contact us for more information!

FAQ
Q.Accepted terms of delivery?
A.We accept FOB,CFR,CIF,ect.You can choose the one which is the most convenient or cost effective for you
Q .How to order ?
A.Please send us your purchase order by email or fax .Or you can ask us to send a proforma invoice for you order . We need to know the following information for your order.
Q .Do you provide samples? Is it free or extra?
A.Yes,we could offer free steel pipe sample for your evaluation.
