API 5CT is standard technical specifications for steel casing pipes used for oil wells in petroleum and natural gas industries.
OD: 114.3-508mm
WT: 5.21-16.13mm
Product Introduction
Technical data
Related Products
Service
Related Projects
Inquiry
Product Introduction
API 5CT is a specification for casing and piping used in the oil and gas industry. It includes several grades of seamless and welded steel pipe for different applications.

For pipeline applications, the API 5L specification is typically used. It covers seamless and welded steel pipe used to transport gas, water and oil in the natural gas and oil industries. the API 5L specification includes several grades such as A25, A, B, X42, X46, X52, X56, X60, X65, X70, X80 and X100. each grade has specific chemical composition and mechanical property requirements.

Whether you need standard length and diameter pipes and tubing or you need high strength, high tensile, heavy wall linepipe requirements for deep sour wells, drilling, offshore drilling and production, arctic exploration and production, or you need standard linepipes for natural gas, oil or water transport,GNEE can meet the demands of your company. All products are industry standard conforming to or exceeding API, ASTM, ASME, ANSI and other national and international standards.
Technical data

API 5CT Grade L80 Pipe Specification

Specification API 5CT/ISO 11960
Material L80, steel grade
Outer Diameter 4 1/2″-20″, (114.3-508mm)
Wall Thickness 1.0mm – 30 mm
Casing Dimensions 114.3 mm (4.5″) to 406.4 mm (16″)
Tubing Dimensions 26.7 mm (1.05″) to 114.3 mm (4.5″)
Length max 12000mm
Thread type SC(Short round thread), LC(Long round thread), BC(Buttress thread)
API 5L API 5L GR.42 / 46 / 52 / 56 / 60 / 65 / 70 / 80


API 5CT Carbon Steel Pipes Chemical Composition

Grade C≤ Si≤ Mn≤ P≤ S≤ Cr≤ Ni≤ Cu≤ Als≤
API 5CT L80 0.15-0.22 1.00 0.25-1.00 0.020 0.010 12.0-14.0 0.20 0.20 0.020


Grade L80 Casing Pipe Dimension Tolerance

Types of steel tubes Outer Diameter Wall Thickness
Cold-rolled tubes Tube sizes(mm) Tolerances(mm) Tolerances(mm)
<114.3 ±0.79 -12.5%
≥114.3 -0.5%,+1%


API 5CT Line Pipe Mechanical Properties

Steel Grade Yield Strength (Mpa) Tensile Strength (Mpa)
API 5CT L80 552-655 ≥655












Related Products
Service
Certification and testing as per clients need
Third party inspections and approval
Inventory management as per clients
Logistics arrangement for client to help in cost cutting
Related Projects
Neutral gas subsea transportation
2024-06-12 09:55:34
Neutral gas subsea transportation
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
Belgium Offshore Engineering
2024-07-24 10:09:13
Belgium Offshore Engineering
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
French oil pipeline project
2024-06-27 18:45:44
French oil pipeline project
standard:ASTM
Surface :1. Galvanized 2. Black and Color Painting
