COLD DRAWN SEAMLESS PIPE
Cold drawn seamless tubing possesses a high strength-to-weight ratio and can be processed to provide a combination of desired characteristics.
| Nominal OD (IN) | Wall Thickness (GA or IN) | Wall Thickness Dec (IN) | Nominal ID (IN) | Weight per Foot (LB) |
|---|---|---|---|---|
| 1/2 | 16 | 0.07 | 0.37 | 0.38 |
| 3/4 | 16 | 0.07 | 0.62 | 0.61 |
| 3/4 | 14 | 0.08 | 0.58 | 0.75 |
| 3/4 | 11 | 0.12 | 0.51 | 1.03 |
| 1 | 16 | 0.07 | 0.87 | 0.827 |
| 1 | 15 | 0.07 | 0.87 | 0.91 |
| 1 | 14 | 0.08 | 0.83 | 1.04 |
| 1 | 12 | 0.11 | 0.78 | 1.32 |
| 1 | 11 | 0.12 | 0.76 | 1.44 |
| 1 1/4 | 16 | 0.07 | 1.12 | 1.05 |
| 1 1/4 | 14 | 0.08 | 1.08 | 1.32 |
| 1 1/4 | 11 | 0.12 | 1.01 | 1.84 |
| 1 1/4 | 3/16 | 0.19 | 0.87 | 2.4 |
| 1 1/2 | 16 | 0.07 | 1.37 | 1.27 |
| 1 1/2 | 14 | 0.08 | 1.33 | 1.6 |
| 1 1/2 | 12 | 0.11 | 1.28 | 2.06 |
| 1 1/2 | 11 | 0.12 | 1.26 | 2.25 |
| 1 1/2 | 3/16 | 0.19 | 1.12 | 3.04 |
| 1 1/2 | 1/4 | 0.25 | 1.00 | 4.07 |
| 1 3/4 | 14 | 0.08 | 1.58 | 1.88 |
| 1 3/4 | 11 | 0.12 | 1.51 | 2.66 |
| 2 | 16 | 0.07 | 1.87 | 1.71 |
| 2 | 14 | 0.08 | 1.83 | 2.16 |
| 2 | 12 | 0.11 | 1.78 | 2.8 |
| 2 | 11 | 0.12 | 1.76 | 3.07 |
| 2 | 3/16 | 0.19 | 1.62 | 4.32 |
| 2 | 1/4 | 0.25 | 1.50 | 5.41 |
| 2 1/2 | 14 | 0.08 | 2.33 | 2.73 |
| 2 1/2 | 11 | 0.12 | 2.26 | 3.9 |
| 2 1/2 | 3/16 | 0.19 | 2.12 | 5.59 |
| 2 1/2 | 1/4 | 0.25 | 2.00 | 7.11 |
| 3 | 14 | 0.08 | 2.83 | 3.26 |
| 3 | 11 | 0.12 | 2.76 | 4.75 |
| 3 | 3/16 | 0.19 | 2.62 | 6.87 |
| 3 | 1/4 | 0.25 | 2.50 | 8.81 |
| 3 | 3/16 | 0.31 | 2.37 | 10.58 |
| 3 | 3/8 | 0.38 | 2.25 | 12.16 |
| 3 1/2 | 11 | 0.12 | 3.26 | 5.6 |
| 3 1/2 | 3/16 | 0.19 | 3.12 | 8.15 |
| 3 1/2 | 1/4 | 0.25 | 3.00 | 10.51 |
| 3 1/2 | 5/16 | 0.31 | 2.87 | 12.7 |
| 4 | 14 | 0.08 | 3.83 | 4.32 |
| 4 | 11 | 0.12 | 3.76 | 6.46 |
| 4 | 3/16 | 0.19 | 3.62 | 9.42 |
| 4 | 1/4 | 0.25 | 3.50 | 12.21 |
| 4 | 3/16 | 0.31 | 3.37 | 14.83 |
| 4 | 3/8 | 0.38 | 3.25 | 17.27 |
| 4 | 1/2 | 0.50 | 3.00 | 21.63 |
| 4 1/2 | 3/16 | 0.19 | 4.12 | 10.7 |
| 4 1/2 | 1/4 | 0.25 | 4.00 | 13.91 |
| 5 | 3/16 | 0.19 | 4.62 | 11.97 |
| 5 | 1/4 | 0.25 | 4.50 | 15.62 |
| 5 | 3/16 | 0.31 | 4.37 | 19.08 |
| 5 | 3/8 | 0.38 | 4.25 | 22.37 |
| 5 | 1/2 | 0.50 | 4.00 | 28.43 |
| 6 | 3/16 | 0.19 | 5.62 | 14.53 |
| 6 | 1/4 | 0.25 | 5.50 | 19.02 |
| 6 | 5/16 | 0.31 | 5.37 | 23.34 |
| 6 | 3/8 | 0.38 | 5.25 | 27.48 |
| 6 | 1/2 | 0.50 | 5.00 | 35.24 |
| 6 | 3/8 | 0.63 | 4.75 | 42.26 |
| 7 | 3/16 | 0.19 | 6.62 | 17.08 |
| 7 | 1/4 | 0.25 | 6.50 | 22.42 |
| 7 | 5/16 | 0.31 | 6.37 | 27.59 |
| 7 | 3/8 | 0.38 | 6.25 | 32.58 |
| 7 | 1/2 | 0.50 | 6.00 | 42.05 |
| 8 | 3/16 | 0.19 | 7.62 | 19.63 |
| 8 | 1/4 | 0.25 | 7.50 | 25.82 |
| 8 | 5/16 | 0.31 | 7.37 | 31.84 |
| 8 | 3/8 | 0.38 | 7.25 | 37.69 |
| 8 | 1/2 | 0.50 | 7.00 | 48.85 |
| 8 | 3/8 | 0.63 | 6.75 | 59.32 |
| 10 | 3/16 | 0.19 | 9.62 | 24.73 |
| 10 | 1/4 | 0.25 | 9.50 | 32.63 |
| 10 | 5/16 | 0.31 | 9.37 | 40.35 |
| 10 | 3/8 | 0.38 | 9.25 | 47.9 |
| 10 | 1/2 | 0.50 | 9.00 | 62.46 |
| 10 | 3/8 | 0.63 | 8.75 | 76.33 |
| 12 | 1/4 | 0.25 | 11.50 | 39.43 |
| 12 | 5/16 | 0.31 | 11.37 | 48.86 |
| 12 | 3/8 | 0.38 | 11.25 | 58.1 |
| 12 | 1/2 | 0.50 | 11.00 | 76.07 |
| 12 | 3/8 | 0.63 | 10.75 | 93.25 |
| 14 | 5/16 | 0.31 | 13.37 | 57.36 |
| 14 | 3/8 | 0.38 | 13.25 | 68.31 |
| 14 | 1/2 | 0.50 | 13.00 | 89.68 |
| 14 | 3/8 | 0.63 | 12.75 | 110.36 |
| 16 | 5/16 | 0.31 | 15.37 | 65.87 |
| 16 | 3/8 | 0.38 | 15.25 | 78.52 |
| 16 | 1/2 | 0.50 | 15.00 | 103.3 |
| 16 | 3/8 | 0.63 | 14.75 | 127.37 |
