ASTM A671
Nominal Size Long Side (IN) | Nominal Size Short Side (IN) | Wall Thickness (GA or IN) | Wall Thickness Dec (IN) | Weight per Foot (LB) |
---|---|---|---|---|
1-1/2 | 3/4 | 14 | 0.083 | 1.18 |
1-1/2 | 1 | 16 | 0.065 | 1.05 |
1-1/2 | 1 | 14 | 0.083 | 1.32 |
1-1/2 | 1 | 11 | 0.12 | 1.84 |
2 | 1 | 16 | 0.065 | 1.27 |
2 | 1 | 14 | 0.083 | 1.6 |
2 | 1 | 11 | 0.12 | 2.25 |
2 | 1 1/2 | 14 | 0.083 | 1.88 |
2 | 1 1/2 | 11 | 0.12 | 2.66 |
2-1/2 | 1 1/2 | 14 | 0.083 | 2.16 |
2-1/2 | 1 1/2 | 11 | 0.12 | 3.07 |
2-1/2 | 1 1/2 | 3/16 | 0.188 | 4.32 |
3 | 1 | 14 | 0.083 | 2.16 |
3 | 1 | 11 | 0.12 | 3.05 |
3 | 1 1/2 | 14 | 0.083 | 2.45 |
3 | 1 1/2 | 11 | 0.12 | 3.48 |
3 | 1 1/2 | 3/16 | 0.188 | 4.94 |
3 | 2 | 14 | 0.083 | 2.73 |
3 | 2 | 11 | 0.12 | 3.9 |
3 | 2 | 3/16 | 0.188 | 5.59 |
3 | 2 | 1/4 | 0.25 | 7.11 |
3-1/2 | 2 1/2 | 3/16 | 0.188 | 6.87 |
4 | 2 | 14 | 0.083 | 3.26 |
4 | 2 | 11 | 0.12 | 4.75 |
4 | 2 | 3/16 | 0.188 | 6.87 |
4 | 2 | 1/4 | 0.25 | 8.81 |
4 | 2 | 3/16 | 0.313 | 10.58 |
4 | 3 | 11 | 0.12 | 5.61 |
4 | 3 | 3/16 | 0.188 | 8.15 |
4 | 3 | 1/4 | 0.25 | 10.51 |
4 | 3 | 5/16 | 0.313 | 12.7 |
4 | 3 | 3/8 | 0.375 | 14.71 |
5 | 2 | 11 | 0.12 | 5.6 |
5 | 2 | 3/16 | 0.188 | 8.15 |
5 | 2 | 1/4 | 0.25 | 10.51 |
5 | 2 | 5/16 | 0.313 | 12.7 |
5 | 3 | 11 | 0.12 | 6.45 |
5 | 3 | 3/16 | 0.188 | 9.42 |
5 | 3 | 1/4 | 0.25 | 12.21 |
5 | 3 | 5/16 | 0.313 | 14.83 |
5 | 3 | 3/18 | 0.375 | 17.27 |
5 | 3 | 1/2 | 0.5 | 21.63 |
5 | 4 | 3/16 | 0.188 | 10.7 |
5 | 4 | 1/4 | 0.25 | 13.91 |
6 | 2 | 11 | 0.12 | 6.46 |
6 | 2 | 3/16 | 0.188 | 9.42 |
6 | 2 | 1/4 | 0.25 | 12.21 |
6 | 2 | 5/16 | 0.313 | 14.83 |
6 | 2 | 3/8 | 0.375 | 17.27 |
6 | 3 | 3/16 | 0.188 | 10.7 |
6 | 3 | 1/4 | 0.25 | 13.91 |
6 | 3 | 5/16 | 0.313 | 16.96 |
6 | 3 | 3/8 | 0.375 | 19.82 |
6 | 4 | 11 | 0.12 | 7.96 |
6 | 4 | 3/16 | 0.188 | 11.97 |
6 | 4 | 1/4 | 0.25 | 15.62 |
6 | 4 | 5/16 | 0.313 | 19.08 |
6 | 4 | 3/8 | 0.375 | 22.37 |
6 | 4 | 1/2 | 0.5 | 28.43 |
7 | 3 | 1/4 | 0.25 | 15.62 |
7 | 4 | 3/16 | 0.188 | 13.25 |
7 | 4 | 1/4 | 0.25 | 17.32 |
7 | 4 | 3/8 | 0.375 | 24.93 |
7 | 5 | 1/4 | 0.25 | 19.02 |
7 | 5 | 3/8 | 0.375 | 27.48 |
7 | 5 | 1/2 | 0.5 | 35.24 |
8 | 2 | 3/16 | 0.188 | 11.97 |
8 | 2 | 1/4 | 0.25 | 15.62 |
8 | 2 | 3/8 | 0.375 | 22.37 |
8 | 3 | 3/16 | 0.188 | 13.25 |
8 | 3 | 1/4 | 0.25 | 17.32 |
8 | 3 | 3/8 | 0.375 | 24.93 |
8 | 4 | 3/16 | 0.188 | 14.53 |
8 | 4 | 1/4 | 0.25 | 19.02 |
8 | 4 | 5/16 | 0.313 | 23.34 |
8 | 4 | 3/8 | 0.375 | 27.48 |
8 | 4 | 1/2 | 0.5 | 35.24 |
8 | 6 | 3/16 | 0.188 | 17.08 |
8 | 6 | 1/4 | 0.25 | 22.42 |
8 | 6 | 5/16 | 0.313 | 27.59 |
8 | 6 | 3/8 | 0.375 | 32.58 |
8 | 6 | 1/2 | 0.5 | 42.05 |
9 | 5 | 3/16 | 0.188 | 17.08 |
9 | 5 | 1/4 | 0.25 | 22.42 |
9 | 5 | 5/16 | 0.313 | 27.59 |
9 | 5 | 3/8 | 0.375 | 32.58 |
9 | 5 | 1/2 | 0.5 | 42.05 |
9 | 7 | 3/16 | 0.188 | 19.63 |
9 | 7 | 1/4 | 0.25 | 25.82 |
9 | 7 | 5/16 | 0.313 | 31.84 |
9 | 7 | 3/8 | 0.375 | 37.69 |
9 | 7 | 1/2 | 0.5 | 48.85 |
9 | 7 | 5/8 | 0.625 | 59.32 |
10 | 2 | 3/16 | 0.188 | 14.53 |
10 | 2 | 1/4 | 0.25 | 19.02 |
10 | 2 | 5/16 | 0.313 | 23.34 |
10 | 2 | 3/8 | 0.375 | 27.48 |
10 | 3 | 3/16 | 0.188 | 13.99 |
10 | 3 | 1/4 | 0.25 | 20.72 |
10 | 3 | 5/16 | 0.313 | 25.46 |
10 | 3 | 3/8 | 0.375 | 30.03 |
10 | 4 | 3/16 | 0.188 | 17.08 |
10 | 4 | 1/4 | 0.25 | 22.42 |
10 | 4 | 5/16 | 0.313 | 27.59 |
10 | 4 | 3/8 | 0.375 | 32.58 |
10 | 4 | 1/2 | 0.5 | 42.05 |
10 | 6 | 3/16 | 0.188 | 19.63 |
10 | 6 | 1/4 | 0.25 | 25.82 |
10 | 6 | 3/8 | 0.375 | 37.69 |
10 | 6 | 1/2 | 0.5 | 48.85 |
10 | 8 | 1/4 | 0.25 | 29.23 |
10 | 8 | 3/8 | 0.375 | 42.79 |
12 | 2 | 3/16 | 0.188 | 17.08 |
12 | 2 | 1/4 | 0.25 | 22.42 |
12 | 4 | 3/16 | 0.188 | 19.63 |
12 | 4 | 1/4 | 0.25 | 25.82 |
12 | 4 | 5/16 | 0.313 | 31.84 |
12 | 4 | 3/8 | 0.375 | 37.69 |
12 | 4 | 1/2 | 0.5 | 48.85 |
12 | 6 | 3/16 | 0.188 | 22.18 |
12 | 6 | 1/4 | 0.25 | 29.23 |
12 | 6 | 3/8 | 0.375 | 42.79 |
12 | 6 | 1/2 | 0.5 | 55.66 |
12 | 6 | 5/8 | 0.625 | 67.82 |
12 | 8 | 3/16 | 0.188 | 24.73 |
12 | 8 | 1/4 | 0.25 | 32.63 |
12 | 8 | 5/16 | 0.313 | 40.35 |
12 | 8 | 3/8 | 0.375 | 47.9 |
12 | 8 | 1/2 | 0.5 | 62.46 |
12 | 8 | 5/8 | 0.625 | 76.33 |
12 | 10 | 1/4 | 0.25 | 36.03 |
12 | 10 | 5/16 | 0.313 | 44.6 |
12 | 10 | 3/8 | 0.375 | 53 |
12 | 10 | 1/2 | 0.5 | 69.26 |
14 | 4 | 3/16 | 0.188 | 22.18 |
14 | 4 | 1/4 | 0.25 | 29.23 |
14 | 4 | 5/16 | 0.313 | 36.1 |
14 | 4 | 3/8 | 0.375 | 42.79 |
14 | 4 | 1/2 | 0.5 | 55.66 |
14 | 6 | 3/16 | 0.188 | 24.73 |
14 | 6 | 1/4 | 0.25 | 32.63 |
14 | 6 | 5/16 | 0.313 | 40.35 |
14 | 6 | 3/8 | 0.375 | 47.9 |
14 | 6 | 1/2 | 0.5 | 62.46 |
14 | 6 | 5/8 | 0.625 | 76.33 |
14 | 10 | 1/4 | 0.25 | 39.43 |
14 | 10 | 3/16 | 0.313 | 48.86 |
14 | 10 | 3/8 | 0.375 | 58.1 |
14 | 10 | 1/2 | 0.5 | 76.07 |
14 | 10 | 5/8 | 0.625 | 93.34 |
16 | 4 | 1/4 | 0.25 | 32.63 |
16 | 4 | 5/16 | 0.313 | 40.35 |
16 | 4 | 3/8 | 0.375 | 47.9 |
16 | 4 | 1/2 | 0.5 | 62.46 |
16 | 8 | 1/4 | 0.25 | 39.43 |
16 | 8 | 5/16 | 0.313 | 48.86 |
16 | 8 | 3/8 | 0.375 | 58.1 |
16 | 8 | 1/2 | 0.5 | 76.07 |
16 | 8 | 5/8 | 0.625 | 93.34 |
16 | 12 | 5/16 | 0.313 | 57.36 |
16 | 12 | 3/8 | 0.375 | 68.31 |
16 | 12 | 1/2 | 0.5 | 89.68 |
16 | 12 | 5/8 | 0.625 | 110.36 |
18 | 6 | 1/4 | 0.25 | 39.43 |
18 | 6 | 5/16 | 0.313 | 48.86 |
18 | 6 | 3/8 | 0.375 | 58.1 |
18 | 6 | 1/2 | 0.5 | 76.07 |
18 | 6 | 5/8 | 0.625 | 93.34 |
18 | 10 | 5/16 | 0.313 | 57.36 |
18 | 10 | 3/8 | 0.375 | 68.31 |
18 | 10 | 1/2 | 0.5 | 89.68 |
18 | 10 | 5/8 | 0.625 | 110.36 |
18 | 14 | 5/16 | 0.313 | 65.87 |
18 | 14 | 3/8 | 0.375 | 78.52 |
18 | 14 | 1/2 | 0.5 | 103.3 |
18 | 14 | 5/8 | 0.625 | 127.37 |
20 | 4 | 1/4 | 0.25 | 39.43 |
20 | 4 | 5/16 | 0.313 | 48.86 |
20 | 4 | 3/8 | 0.375 | 58.1 |
20 | 4 | 1/2 | 0.5 | 76.07 |
20 | 8 | 5/16 | 0.313 | 57.36 |
20 | 8 | 3/8 | 0.375 | 68.31 |
20 | 8 | 1/2 | 0.5 | 89.68 |
20 | 8 | 5/8 | 0.625 | 110.36 |
20 | 12 | 5/16 | 0.313 | 65.87 |
20 | 12 | 3/8 | 0.375 | 78.52 |
20 | 12 | 1/2 | 0.5 | 103.3 |
20 | 12 | 5/8 | 0.625 | 127.37 |
