What is a forged flange?
Forged flanges combine two separate machinery parts together. They can be an extension to a structure in order to make the object stronger. Industrial flanges have numerous uses including connecting sheets, pumps, pipes and structures that specifically require an intermediate point of connection.
Standard specification for forged flanges
Dimensions: ANSI B16.5, ANSI B16.47 Series A and B, MSS SP44, ASA, API-605, AWWA,
Sizes: 1/2 in. (15 NB) to 48 in. (1200 NB)
Grade: 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN standard ND-6, 10, 16, 25, 40, etc.
DIN: DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629,
DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
BS: BS4504, BS4504, BS1560, BS10
Flange Face Type: Flat Face (FF), Raised Face (RF), Ring Joint (RTJ)
Forged flange material and grade:
Stainless steel forged flange:
ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L
Duplex and Super Duplex Steel Forged Flanges:
ASTM/ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61
Carbon steel forged flange:
ASTM / ASME A/SA 105 ASTM / ASME A 350, ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706
Low temperature carbon steel forged flange: ASTM A350, LF2, LF3
Alloy steel forged flange:
ASTM/ASME A/SA 182 and A 387 F1, F5, F9, F11, F12, F22, F91
